GoDEX EZPi1000 series User Manual
Page 39
EZPi1000 User Manual
35
5. Unscrew the fastening screw on the
Ethernet module.
6. Remove the Ethernet module and its
connection cable.
7. Unscrew the nut on the PS/2 port using a
spanner. Unscrew the earthing screw and
disconnect the cable from the PS/2 port to
remove the PS/2 port. Now tighten the
earthing screw again.
8. Attach the WLAN module to the bracket.
9. Remove the cable tie from the connection
cable and extend the cable to its full
length. Now plug the cable connector into
the Ethernet module socket.
【
Caution
】
Be careful when removing the cable tie to avoid damage to the connection cable.
Note: Please cut the cable tie carefully. Do not damage the Module Connection Wire.
