EZPi1000 User Manual
28
4. Accessories
4-1. Installing the label dispenser
1 Dispenser module
2
1
2 Screws (set of 2)
【 Note 1 】 Remember to
switch off the printer before
installing the label dispenser.
【 Note 2 】 A label liner
thickness of 0.006 mm ± 10%
and a weight of 65 g/m
2 ±
6% are recommended.
【 Note 3 】 The label
dispenser will take labels up
to a max. width of 110 mm.
【 Tip 】 When using the label
dispenser, set the stop
position to 9 mm.
1. Open the printer cover
by pressing the release
buttons on both sides
of the printer housing.
2. Press the release
catches on both sides
of the print mechanism
to open and lift the
print mechanism.
3. To remove the front
cover, press in the two
plastic release tabs.
4.
Remove the front
cover as shown in the
illustration.
