1 Technical Specification
Design Description
The Clearly Solar collector, collects the available solar
radiation and transfers the heat through the solar fluid into the
system.
It has been designed to compliment the complete range of
Glow-worm solar system components.
The kits are suitable for roof pitches between 22°- 75°, please
choose from the table below.
The solar thermal flat plate collector includes a saltwater-
resistant aluminium frame as well as a copper surface
absorber with a high selective coating.
The flat plate collector has a CFC-free, standstill temperature-
resistant mineral wool insulation for long-life and excellent
heat insulation.
Hydraulic connections are push-fit with double ‘O’ ring
sealing. The sensor sleeve is integrated into the hydraulic flow
connection.
The following kits are available and dependant upon the
number of collectors, the quantities required are listed in the
following table and illustrated in the appropriate sections:-
Number of collectors
1
2
3
4
5
6
7
8
9
10
11
12
1 collector in-roof kit
Part number 0020060315
1
-
-
-
-
-
-
-
-
-
-
-
2 collector in-roof kit
Part number 0020060317
-
1
1
1
1
1
1
1
1
1
1
1
Extension kit (additional
collector)
Part number 0020060326
-
-
1
2
3
4
5
6
7
8
9
10
Easy fit hydraulic
connection set - section 4
Part number 0020065271
1
Easy fit hydraulic
extension set - section 4
Part number 0020059909
-
1
2
3
4
5
6
7
8
9
10
11
