Key
1 Hydraulic module
2 Systempro control unit
3 Domestic hot water cylinder
3.1 Top domestic hot water NTC
3.2 Electric heater
3.3 Bottom domestic hot water NTC
4 Electric heater electrical supply + protection (This must have it's
own single isolation)
5 Power relay for the electric heater (not supplied)
6 Heat pump
7 Heat pump circuit fi lter (not supplied)
8 3 port valve
9 Glycol PRV discharge
A Heating circuit return
B Heating circuit fl ow
C Heat pump circuit safety valve discharge
D Heat pump circuit fl ow to module circuit
E Heat pump circuit return
F Cold water supply
G Domestic hot water fl ow
H Heat pump circuit return
I Heat pump circuit fl ow to cylinder circuit
Application conditions
- The Systempro control unit manages the Domestic Hot Water
cylinder.
- The maximum working pressure of the domestic hot water
circuit is 10 bar. If the cold water supply pressure exceeds this,
then a pressure-reducing valve must be fi tted in the supply to
the boiler.
- In areas where the water is ‘hard’ (i.e. more than 200 mg/L
of calcium carbonate), it is recommended that the hot water
setting is reduced and that a scale reducer is fi tted, refer to the
manufacturer’s instructions or consult the local water company
for additional advice.
e
Use 0.75 mm² section cables for the electrical
connections to the control unit.
Control unit settings with eBus heat pump
Description of main settings Setting
Diagram no. 4
Option choice: Domestic Hot Water cylinder On
The type of tank
NTC sensor (1 top NTC)
or
NTC sensor (2 NTC)
Control unit settings with heat pump controlled by On/Off contact
Description of main settings Setting
Diagram no. 7
Option choice: Domestic Hot Water cylinder On
The type of tank NTC sensor (2 NTC)
