FeiYu Tech FY-91Q User Manual
Page 18
GuiLin FeiYu Electronic Technology Co., Ltd
GuiLin FeiYu Electronic Technology Co., Ltd www.feiyudz.cn E-mail: [email protected]
Page 17
X - Type Hexa Layout:
1 = ESC 1 CW
2 = ESC 2 CW
3 = ESC 3 CW
4 = ESC 4 CCW
5 = ESC 5 CCW
6 = ESC 6 CCW
CW = clock wise
CCW = counter clockwise
1
6
3
4
2
5
E
S
C
1
E
S
C
4
E
S
C
3
E
S
C
2
RUD
THR
ELE
AIL
CH5
GSP&CPMPASS
AP117 OSD
Data Radio
PC setting
E S C 5 (P1)
E S C 6(P2)
GPS
Y-Cable
(included)
FY-91Q Hexa Copter Setup
1
2
3
4
