X-type layout, Cross type layout – FeiYu Tech FY-91Q User Manual
Page 15
GuiLin FeiYu Electronic Technology Co., Ltd
GuiLin FeiYu Electronic Technology Co., Ltd www.feiyudz.cn E-mail: [email protected]
Page 14
Quadcopter Set Up
1
2
3
4
X-Type QuadCopter Layout:
1
= ESC 1 CCW
2
= ESC 2 CW
3
= ESC 3 CCW
4
= ESC 4 CW
cw = clock wise
ccw = counter clockwise
X-Type Layout
1
2
3
4
1
2
3
4
十 - Type Quad Layout:
1
= ESC 1 CCW
2
= ESC 2 CW
3
= ESC 3 CCW
4
= ESC 4 CW
cw = clock wise
ccw = counter clockwise
Cross Type Layout
1
2
3
4
