FeiYu Tech FY-91Q User Manual
Page 10
GuiLin FeiYu Electronic Technology Co., Ltd
GuiLin FeiYu Electronic Technology Co., Ltd www.feiyudz.cn E-mail: [email protected]
Page 9
d. The red LED light will flash in two different rates.
e. After approximately 20 seconds, the initialization process is complete.
f. Disconnect the power supply and unplug the jumper (please keep in a
safe place for future use).
FY-91Q Connection Interface Diagram
Interface Pin Panel Connection:
8
7
6
5
4
3
2
1
舵
机
1
2
3
4
5
6
7
8
III
IV
1
2
Jumper installed
during gyro
initialization.
Do not insert
jumper during
normal use.
ESC 5 and ESC 6
Connection
Pitch sensitivity knob
Flight Course (Yaw)
sensitivity knob
Flight mode LED
indicator. (Blue)
GPS status and Vibration
level LED light
indicator. (Red)
Arrow must point towards
aircraft direction of flight.
Interface Pin Panel
(see below)
DIP switch
(mode selection)
Roll sensitivity knob
I
II
