Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyudz.cn E-mail: [email protected] Page 6
3.Stick the cover board to the DoS upper surface (LOGO character surface); you can
appropriately increase DOS module weight to improve the damping effect, you can stick
copper sheet or other sheet metal which cannot be magnetized on the bottom of the DOS
(Otherwise the magnetized sheet metal will disturb the internal magnetic field sensors).If
cannot then a coin maybe also OK as the current firmware version without GPS point
hovering function the disturb is not so obvious.
4.Use screws to fix the cover board to the four support columns;
5.Stick the circular ring foam pads (dampers) to the four rounded corners on the baseboard
vibration absorbing mount.Then fix it as far as possible to the position of barycentre on
aircraft
7. RC receiver connection:
RC receiver and DoS connection wires is included in the DoS product. Attention: the
wires is arranged by the colors.
