has to be in the center position. To prevent the altitude sudden change caused by the
throttle, you have to put throttle stick back to balance flight position, when switch off fixed
altitude flight mode.
1. DoS standard configuration：
Standard configuration
●DoS control module *1;
●RC receiver connecting wires * 1;
●USB cable *1;
●Velcro double sided tape * 2;
Optional accessory
●DoS vibration absorbing mount *1;
●GPS module *1;
●Hornet OSD module;
●Data Radio;
●Remote Adaptor;
2. Technical Specification:
DoS module
Input voltage
: 4.0 ~ 6.0 Volt;
Current
: 50mA (5V);
Size
: 47 x 30 x 11 mm;
Weight (excluding wires)
: 25g;
Temperature range
: -25 ° C ~ +70 ° C;
Control frequency
:400HZ
Maximum rate of rotation
: ≤ 2000 °/s.
3. Interface specifications:
Remote receiver input interface
No.
1
2
3
4
RC
receiver
interface
SW1
RUD
Servo
THR
Servo
ELE
Servo
GND
Power
+5V
AIL
Servo
SW2
