MAX-700 339
A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
TECHNICAL SPECIFICATIONS M
AX
T
ESTER
710-P
Display Touchscreen, color, 800 x 480 TFT, 178 mm (7 in)
Interfaces Two USB 2.0 ports
RJ-45 LAN 10/100/1000 Mbit/s
Fiber inspection probe connector port (video)
Built-in Bluetooth and Wi-Fi (hardware option)
Storage 4 GB internal memory (flash)
Batteries Rechargeable lithium-ion batteries
7 hours of operation as per Telcordia (Bellcore)
TR-NWT-001138
Power supply AC/DC adapter, input 100-240 VAC, 50-60 Hz,
1.6 A max, output 24 VDC, 3.75 A
Computer Intel ATOM processor
Windows Embedded Standard operating system
Wavelength (nm) b 1310 ± 20/1550 ± 20
Dynamic range (dB) c 34/32
Event dead zone (m) d 0.8
Attenuation dead zone (m) 5
Distance range (km) Singlemode: 1.25, 2.5, 5, 10, 20, 40, 80, 160, 260
Pulse width (ns) Singlemode: 5, 10, 30, 50, 100, 275, 500,
1000, 2500, 10 000, 20 000
Linearity (dB/dB) ±0.03
Loss threshold (dB) 0.01
Loss resolution (dB) 0.001
Sampling resolution (m) Singlemode: 0.04 to 5
Sampling points Up to 128 000
Distance uncertainty (m) e ±(0.75 + 0.0025 % x distance + sampling resolution)
Measurement time User-defined (60 min. maximum)
Typical real-time refresh (Hz) 3
Stable source output power (dBm) f –7
SPECIFICATIONS a
Notes
a. All specifications valid at 23 °C ± 2 °C with an FC/APC connector, unless otherwise specified.
b. Typical.
c. Typical dynamic range with longest pulse and three-minute averaging at SNR = 1.
d. Typical dead zone for reflectance below –45 dB, using a 5 ns pulse.
e. Does not include uncertainty due to fiber index.
f. Typical output power is given at 1550 nm.
