EXFO EXpert IPTV Test Tools (FTB-200v2) - Manual (Page 25)

25
For VoD streams (uri’s):
 Choose the RTSP uri to be tested from the
Channel List in the STB
 Click on Play button of the chosen channel in
the Set Top Box. This will initiate RTSP join
request for this unicast channel. Once the
stream in this is detected it will show up in the
Test Log box as active. Repeat this process for
all channels to be tested.
To stop the test of the specific stream press button, or press either
or disconnect the Ethernet cable.
7.4 Ethernet Interface Status
The Interface panel shows the status of the
selected Ethernet link.
This information is useful to check if the link is
up or down.
The Downstream Rate give the aggregate kbits/s for the all the streams present in the link.
