Eskape ™ 400 Hardwater Series (69164)
Page 1
GetEskimo.com
HIGH PERFORMANCE ICE FISHING GEAR
1-800-345-6007
®
PARTS lISTS
REf.
NO. DESCRIPTION PART NO. QTy.
1 BOLT, 1/4-20 X 3/4” HH gR5 8930 8
2 WASHER, 1/4” 48261B 6
3 POLE ASSEMBLy, 45.75” SPREADER (INCLUDES TWO .706” LARgE CLIPS) 68035 2
4 POLE ASSEMBLy, SPREADER FEMALE 22.16” (INCLUDES ONE .875” LARgE CLIPS) 68046 4
5 NUT, 1/4-20 HNyLk ZN 67538 22
6 BOLT 1/4-20 X 1” HHCS gR5 ZN 69345 14
7 RISER, HINgE LEFT 68052 2
8 RISER, HINgE RIgHT 68053 2
9 POLE ASSEMBLy, CROSS BRACE WITH PLASTIC E400 68134 6
10 HINgE ASSEMBLy, RIgHT HAND 68145 2
11 HINgE ASEMBLy, LEFT SIDE 68146 2
12 POLE ASSEMBLy, SPREADER MALE 38.59” (INCLUDES ONE .706” LARgE CLIP) 68148 4
13 BOX, ROD HOLDER 68159 2
14 SUPPORT, TUB 68161 2
15 POLE ASSEMBLy, SPREADER FEMALE 22 1/8” (INCLUDES ONE .875” LARgE CLIP AND
THUMB SCREW) 68167 1
16 POLE ASSEMBLy, SPREADER MALE 23 5/8” (INCLUDES ONE .706” LARgE CLIP) 68165 1
17 SLED 69190 1
18 SEAT kIT-see seat kit parts breakdown 69299 2
19 NUT, 1/4-20 TOP LOCk FLANgED BLk 48752B 12
20 BOLT 1/4-20 X 2-1/2” PHILLIPS TRUSS HD 67430 12
21 POLE ASSEMBLy, UPRIgHT 28.75” 68029 8
22 RIgHT HINgE, DOUBLE SIDED HOLE 68051 4
23 POLE ASSEMBLy, J-POLE 27 7/8” RIgHT 68059 2
24 CAP, POCkET POLE HINgE 68060 12
25 LEFT HINgE, DOUBLE SIDED HOLE 68076 4
26 CLIP, QRS POLE 68061 12
27 LEFT HINgE, DOUBLE SIDED HOLE 68067 2
ITEmS BElOW NOT SHOWN
- CAP END, ROD HOLDER BOX 68156 2
- SCREW, 10-32 X 1/4” PAN HD 68136 16
- CLIP, LARgE .875” 68064 5
- CLIP, LARgE .706” 68063 9
- TOW ROPE 67589 1
- SHELTER SkIN, RED 68022 1
- WINDOW REPLACEMENT, 8” X 12” 69531 4
- WINDOW REPLACEMENT, 13.5” X 13.5” 69534 4
REPAIR PARTS
- PATCH kIT, RED 69742 -
