CP-10 ENMET Corporation
12
Normal Gas Display 20.9%
Menu Press and H
OLD the M ENU button for 2 – 4 seconds to enter the Maintenance Menus
Exit
Select
➨
Press the Select button to return to the Normal Gas Display. See Section 5.2.1
Menu
Press the Menu button to cycle through Maintenance Menus
mA Span
Menu
Select
➨
30.0
To change mA Span set point:
Press Menu button until mA Span is displayed
Press Select button to display the set point
The Menu button changes digit indicated by underscore cursor
The Select button locks underscored digit and moves to next digit
See Section 5.2.4
To return to Normal Gas Display:
Press M
ENU button until EXIT is displayed
Then press S ELECT button
To change Alarm set points:
Press Menu switch until Alarm to be changed is displayed
Press Select switch to display the set point
The M ENU switch: changes digit indicated by underscore
cursor
The S
ELECT switch: locks in the underscored digit and
moves to next digit
If change is not within range display returns to first digit
If change is within range display moves to Set Time Delay
Use M ENU and S ELECT switches as above to change time
delay. Between 0 and 5 seconds is allowed
If change is within range display moves to next menu
See Section 5.2.3
Λ
- Indicates increasing alarm
V - Indicates decreasing alarm SetTDsec
0
Alarm3 S ELECT
Λ 23.5
M ENU
SetTDsec
0
Alarm1
M ENU
S ELECT V 17.0
SetTDsec
0
Alarm2
M ENU
S ELECT
V 19.5
420Setup
Menu
Select
➨
Select
➨
Select
➨
mA Trim
Scale4mA 0.0
Scal20mA
30.0
20.9 Cal OK
Select
➨
Menu
Press Select button to set low end of scale:
The Select button locks underscored digit and moves to next digit
The Menu button changes digit indicated by underscore cursor
When last digit is entered CP-10 will advance to full scale set up
Select
➨
Menu
Menu
Select
➨
Press Select button to advance to display trim
To adjust display of CP-10 to match S/T display
The Select button locks underscored digit and moves to next digit
The Menu button changes digit indicated by underscore cursor
When the last digit has been locked in place, Cal OK will appear briefly than
the CP-10 will advance to the next menu, Alarm 1
See Section 5.2.2
Press Select button to advance to full scale
To set full scale :
The Select button locks underscored digit and moves to next digit
The Menu button changes digit indicated by underscore cursor
When last digit is entered CP-10 will advance to display trim
N OTE : Software revision may cause variations of display output.
F IGURE 7: CP-10 Maintenance Menu Flow Chart – Oxygen
