5.0 Maintenance
The CP-10 maintenance menus that are accessed by pressing the M ENU button and S ELECT button as described in the
maintenance menu section.
5.1 Maintenance Menus
Pushbutton switches control the M ENU and S ELECT functions. The M ENU and S ELECT button locations are indicated on the
display panel, see Figure 1. The M ENU button is used to display the various menu options and make incremental changes to
numbers such as alarm points. The S ELECT button is used to select the option and move the cursor.
To enter the maintenance menu press and hold the M ENU button for 2 to 4 seconds
Table 2 indicates the maintenance menu sequence see Figure 6 for a detailed maintenance menu flow chart.
N OTE : Software revision may cause variations of display output.
T ABLE 2: CP-10 Maintenance Menus Sequence
Example of Display Function
Normal Display Mode
Measurement of CO
Press and hold the M ENU button for 2 – 4 seconds to enter the Maintenance Menu
The Power/Fault LED will flash Green – Red to indicate the CP-10 is in Maintenance Mode
To exit the maintenance Menu and return to the
Normal Display Mode:
If intended function Press S ELECT button
Press the M ENU button to advance to 4 & 20 Setup procedures
For adjusting the 4 and 20 mA circuit:
If Intended function Press S ELECT button
Press the M ENU button to advance to each Alarm set point procedures
For adjusting the Alarm 1, 2 and 3 set points:
If Intended function Press
S ELECT button
Press the M ENU button to advance the mA Span set point procedure
For adjusting the mA Span set point:
If intended function Press
S ELECT button
Pressing the M ENU button without pressing the S ELECT button will allow you to cycle through the menu options.
You must Press the S ELECT button in order to initiate the desired operation.
5ppm
Exit
mA Span
Alarm1
Alarm2
Alarm3
420Setup
