ENMET CP-10 - Manual (Page 10)

CP-10 ENMET Corporation
8
4.0 Operation
When the CP-10 is installed as described in Section 3, and in clean air, the POWER green LED is on, the display is lit and the
information on the display is measurement of the target detected by the CP-10. The red alarm and fault LEDs are not lit.
4.1 Start Up CP-10
When the CP-10 is first powered up, it goes through a series of momentary screens, which identify the instrument model number,
serial number and software revision. After all of the momentary screens have been displayed, the instrument arrives at the Main
Gas Display showing the gas concentration and unit of measurement in ppm, % or %LEL.
Depending on transmitter configuration and calibration condition, the furthest right character in the display may flash a letter
indicating the instrument status. See the Section 4.1.1 below
4.1.1 Typical Start Up
When power is supplied to the CP-10 , the instrument will display the following sequence of information:
Typical start up sequence of information displayed.
Example of Typical Start Up Display Function
The instrument: Model CP-10
Example for reference only
The instrument: Serial Number
Example for reference only
The instrument: Software Revision
IF the right most character is a flashing W The instrument is in Warm-up mode
This should last about 1 minute
The Signal Output is held at 4mA during warm-up
The instrument: Normal Display Mode
Measurement of the target gas
PPM Parts Per Million
%
Percent By Volume
LEL Lower Explosive Limit
F
Fault, Sensor/Transmitter is not connected or
wiring is not correct
N OTE : Software revision may cause variations of display output.
CP-10
130-1256
S/W X.X
0ppW
0ppm
0LEL
20.9%
