4.2 Normal Display Mode
When the
AM-5175
is installed as described in section 3, and in clean air, the
POWER
green LED is on, the display is lit and
the information on the display in measurement units of ppm detected by the
AM-5175.
The red alarm and fault LEDs are not
lit.
To advance through displays of operational information press the
M
ENU
button.
N
OTE
:
Software revision may cause variations of display output.
See sequence of operational information below:
Display Measurement of the target gas
Press
M
ENU
button
Display indicates Alarm 1 Set point
Press
M
ENU
button
Display indicates Alarm 2 Set point
Press
M
ENU
button
Press
S
ELECT
button
To temporally disable audio
alarm, see Section 4.2.1
Display indicates Alarm 3 Set point
Press
M
ENU
button
Display indicates mA Span range
(Full Scale)
Press
M
ENU
button
Display returns to gas measurent
Operational Display Flow Chart
4.2.1 Alarm Conditions
AM-5175
There are three alarm set points available. These alarm points are normally set at established safety levels, such as the OSHA
Permissible Exposure Limit (PEL) for toxic gases.
These alarm set points can be changed within limits; see the maintenance section of this manual for the procedure.
If the gas concentration increases above that of the alarm set point, the associated red LED is lit, the associated relay changes
state, and the audio alarm is activated.
Pressing the
S
ELECT
button can temporally disable the Audio Alarm. The horn will be disabled for about five minutes. If a
second alarm condition occurs during this time the horn will re-activate. If the alarm condition(s) have ended during this time
the horn will not re-activate.
