AM-5150 ENMET Corporation
15
5.2.4 Alarm Set Points
The AM-5150 has three alarm set points set at the factory. These alarm points are normally set at established safety levels.
Alarm set points can be changed within limits.
To change any of the three alarm points:
Enter the maintenance menu as shown in Figure 7 AM-5150 Maintenance Menu flow chart.
1. Press the M ENU button until to display Alarm1 is displayed.
2. Press the S ELECT button to initiate alarm set point change
3. Press the M ENU button to change the digit indicated by the underscore cursor
4. Press the S ELECT button to move the cursor to the next digit
When last digit is entered the AM-5150 will advance to the next menu
5. Press the M ENU button to advance to the next menu
N OTE : Alarms 2 and 3 can not be set below the Alarm 1 setting.
Example of Alarm Set Point menus:
N OTE : Software revision may cause variations of display output.
5.2.5 mA Span Set
The AM-5150 4-20mA span range is set at the factory, normally to the full scale of the measurement and can be changed
within limits.
To change the span range:
Enter the maintenance menu as shown in Figure 7 AM-5150 Maintenance Menu flow chart.
1. Press the M ENU button until to display Span is displayed.
2. Press the S ELECT button to initiate the mA Span menu
3. Press the M ENU button to change the digit indicated by the underscore cursor
4. Press the S ELECT button to move the cursor to the next digit
When last digit is entered the AM-5150 will advance to the next menu
5. Press the M ENU button to advance to the next menu
Example of mA Span menu:
Default mA Span
4mA 20mA
0 ppm 200 ppm
Alarm1
M ENU
Alarm2
M ENU
Alarm3
S ELECT
S ELECT
S ELECT
20
5
5
10
10
To change Alarm set points:
Press Menu button until Alarm to be changed is displayed
Press Select button to display the set point
The M ENU button changes digit indicated by underscore
cursor
The S
ELECT button locks underscored digit and moves to
next digit
If change is not within range display returns to previous digit
If change is within range display moves to next menu
M ENU
mA Span
M ENU
S ELECT
0200
To change mA Span set points:
Press Menu button until mA Span is displayed
Press Select button to display the set point
The M ENU button changes digit indicated by underscore cursor
The S ELECT button locks underscored digit and moves to next digit
