Figure 13. Capacitance Measurement
-26-
Table 5. LCD Display Symbols (continued)
5. Power On Option
To turn off the Auto Power Off function, press and hold any button
(except RESET) while turning the selector knob to any range
position. The Auto Power Off indicator will disappear.
6. Auto Power Off
When the meter has been on for 10 minutes without any action from
the user, the meter will automatically turn off. To restore power to
the meter, turn the rotary switch to a different position, push any
button, or restart the meter.
7. Measurement Range
A measurement range determines the maximum measurement
value. Most of the functions of the meter have more than one range.
1. It is important to select the correct range
• If the range is too small, “OL” shows on the display for overload.
• If the range is too large, the value of the reading will be very
small with less resolution.
2. Auto range and manual range options
• In the auto range mode, the meter automatically selects the
best range for the input detected.
• In the auto range mode, press the RANGE button to enter
the manual range and select the desired range.
-11-
Sequ. No. Symbol Description
14
Ω / KΩ / MΩ
Hz / KHz / MHz
Resistance units
Frequency units
15
mV / V
nF / μF
μA / mA / A
Voltage units
Capacitance units
Current units
16 Overload + –
CAP
