Check for parts online at
www.getearthquake.com or call 800-345-6007 M-F 8-5
23
Operator's Manual
VECTOR™ Compact Tiller
ITEM #
PART #
DESCRIPTION
QTY.
1
18004
WELDMENT VECTOR FRAME
1
2
13366
LOCK PIN WIRE BALE
1
3
92776
BOLT M6 X 1.0 X 20 HHCS GR8.8 ZN
2
4
18010
HANDLEBAR LOWER STRAP
1
5
W1265V0904
BOLT M8 X 1.25 X 20 HHCS ZN GR8.8
2
6
3245
WASHER M8 8.4MM X 24MM X 2.2MM
ZN
2
7
3252
NUT M8 X 1.25 H GR8.8 ZN
4
8
W1265V0913
NUT M6 X 1.0 HNYLK GR8.8 ZN
10
9
3247
BOLT M8 X 1.25 X 45 HHFCS GR8.8 ZN
2
10
400024
WASHER FLAT M8 8.4 X 16 X 1.6 THK
GR8.8 ZN
2
11
W1200117
WASHER M6 X 13 X 1.75 FLAT ZN
6
12
18123
WELDMENT GUARD PULLEY LOWER
1
13
18103
BOLT M6 X 1.0 X 40 HH GR 8.8 ZN
4
14
331052
NUT M12 X 1.75 HH NYLCK GR8.8 ZN
2
15
W1200116
WASHER M6 X 1.5 SPRLCK ZN
2
16
18119
WELDMENT SHIELD TINE MIDDLE
1
17
10513
BOLT M12 X 1.5 X 96 HH SHLDR M15.7
X 42
2
18
18118
WELDMENT SHIELD TINE RIGHT
1
19
18131
ASSEMBLY DRAG STAKE
1
20
18116
WELDMENT SHIELD TINE LEFT
1
21
18058
BOLT M6 x 1.0 x 12 SBHCS GR8.8 ZN
6
22
10517
WASHER 16MM ID X 25MM OD X 2.5
THK ZN
2
23
15856
WHEEL 8ID X 5/8ID IN RUBBER GRY
2
ILLUSTRATED PARTS BREAKDOWN -
Chassis Assembly
