Operator's Manual
VECTOR™ Compact Tiller
ITEM #
PART #
DESCRIPTION
QTY.
1
18135
BOLT M8 X 1.25 X 25 SFH GR8.8 ZN
6
2
3245
WASHER M8 8.4MM X 24MM X
2.2MM ZN
6
3
64132
NUT M8 X 1.25 HSF
6
4
18011
STRAP HANDLE BAR MIDDLE
2
5
13811
WELDMENT, HANDLEBAR FT PRO
SERIES
1
6
13833
HANDLEBAR GRIP 1 IN ID
2
7
53650
LEVER CONTROL
1
8
3248
NUT M5 X 0.8 HFNYLK
1
9
13159
BOLT 60D X 32 SHLDR M5 X 7MM
HH
1
10
53629
BRACKET CABLE MOUNT
1
11
504
LOCKWASHER-SPRING 5/16"
1
12
12770
BOLT M8 X 1.25 X 40MM HH
1
13
13508
NUT M8 1.0 HSF
1
14
13822
CABLE FT PULLEY 787MM SHEATH
2
15
4620
NUT M8 X 1.25 HJAM
1
16
53620
SPRING COMPRESSION FORWARD
ARM
1
17
IN58
NUT 5M X 0.8 NYLOC
1
18
11397
LINK 260MM LONG
1
19
13601
KNOB M8 THREE STAR
2
20
18010
HANDLEBAR LOWER STRAP
1
21
3308
WASHER FLAT M5 5.3 X 10 X 1.0
1
22
13906
BOLT M8 X 1.25 X 20 SFH
2
ILLUSTRATED PARTS BREAKDOWN -
Handlebar Assembly
