NOTE:.DIAGRAMS.&.ILLUSTRATIONS.ARE.NOT.TO.SCALE.
18
SECTION E - TERMINATIONS, STARTING ADAPTORS, DRAIN
LENGTH AND RELIEF VALVE
STARTING ADAPTORS
Single Wall Adaptor (SWA)
1.. The.Single.Wall.Adaptor.is.used.as.an.appliance.connector...It.is.de-
signed.to.be.clamped.with.a.Retaining.Band.and.a.locking.band.over.
a.shank.type.flue.gas.outlet.
2.. First,.slide.the.retaining.band.over.the.appliance.outlet.and.tighten.it.
with.supplied.bolt..(See.figure 38).
3.. Add.a.bead.of.sealant.about.1/8”.on.the.flange.of.the.retaining.band.
and.one.on.the.flange.of.the.adaptor.(SWA).and.mate.those.two.flanges.
together...Be.sure.to.fill.all.the.gaps.with.S-2000.sealant..(See.figure
39 and figure 40).
4.. Tighten.the.Locking.Band.to.hold.and.seal.the.adaptor.in.place...See.
Figure 41.for.typical.installation.
ANSI Flange Adaptor (FA)
1.. .The.Flange.Adaptor.(FA).is.intended.for.use.as.a.connection.to.a.class.
125.or.150.ANSI.pipe.flange.
2.. This.type.of.connection.requires.a.flange.gasket.and.bolt.set.provided.
by.the.installer...The.gasket.and.bolts.are.typically.sold.by.pipe,.valve.
and.fittings.houses.as.‘NBG’.set.. Figure 42..illustrates.a.typical.instal-
lation.
3.. An.outer.band.with.insulation.is.included.to.close.the.installation.
Flanged Adaptor (FHA)
1.. The.Flanged.Adaptor.(FHA).is.used.to.connect.the.DIS./.DAS.chimney.
to.flanged.appliance.outlets.other.than.those.with.ANSI.pipe.flanges.
2.. The.adaptor.is.designed.to.sandwich.an.1/2.inch.flange.between.two.
half.ring.and.the.appliance.flanged.outlet...The.Flange.Adaptor.comes.
with.beam.clamps.to.clamp.the.FHA.to.the.appliance..See.Figure 43.
DIS/DCT, DCT/DIS, DAS/DCT, DCT/DAS Adaptor
1.. Used.to.connect.model.DIS./.DAS.chimney.to.model.DCT.chimney...
See.Figure 44.
Figure 38 - Single wall adaptor
Figure 39
Figure 40
Figure 41
APPLIANCE
OUTLET
Insert and tighten
the band in place
APPLIANCE
OUTLET
Apply bead
of sealant
APPLIANCE
OUTLET
Insert the
coupling end
APPLIANCE
OUTLET
Tighten the
locking band
OTHER ADAPTORS
Female Single Wall Adaptor (FSWA)
1.. The.Female.Single.Wall.Adaptor.is.used.as.a.connector.to.specialised.
component. or. existing. chimney. connection.. . It. is. designed. to. be.
clamped.with.a.Retaining.Band.and.a.locking.band.over.a.shank.type.
flue.gas.inlet.
2.. First,.slide.the.retaining.band.over.the.system.inlet.and.tighten.it.with.
supplied.bolt..(See.figure 38a).
3.. Add.a.bead.of.sealant.about.1/8”.on.the.flange.of.the.retaining.band.
and.one.on.the.flange.of.the.adaptor.(SWA).and.mate.those.two.flanges.
together...Be.sure.to.fill.all.the.gaps.with.S-2000.sealant..(See.figure
39a and figure 40a).
4.. Tighten.the.Locking.Band.to.hold.and.seal.the.adaptor.in.place...See.
Figure 41a.for.typical.installation.
Female ANSI Flange Adaptor (FFA)
1.. .The.Female.Flange.Adaptor.(FFA).is.intended.for.use.as.a.connection.
to.a.class.125.or.150.ANSI.pipe.flange.
2.. This.type.of.connection.requires.a.flange.gasket.and.bolt.set.provided.
by.the.installer...The.gasket.and.bolts.are.typically.sold.by.pipe,.valve.
and.fittings.houses.as.‘NBG’.set.. Figure 42..illustrates.a.typical.instal-
lation.
3.. An.outer.band.with.insulation.is.included.to.close.the.installation.
Figure 38a - Female Single wall
adaptor
Insert and tighten
the band in place
INLET
Figure 39a
INLET
Apply bead
of sealant
Insert the
coupling end
Figure 40a
Tighten the
locking band
INLET
Female.Flanged Adaptor (FFHA)
1.. The.Flanged.Adaptor.(FFHA).is.used.to.connect.the.DIS.chimney.to.
flanged.appliance.outlets.other.than.those.with.ANSI.pipe.flanges.
2.. The.adaptor.is.designed.to.sandwich.an.1/2.inch.flange.between.two.
half.ring.and.the.appliance.flanged.outlet...The.Flange.Adaptor.comes.
with.beam.clamps.to.clamp.the.FFHA.to.the.appliance..See.Figure 43.
INLET
Figure 41a
