5 Connect the vehicle specific connector and the iPod docking cable to the DICE module. Apply cable ties to secure

the cables.

1/8"

AUX

input

iPod

dock

cable
input

vehicle

specific

connector

vehicle specific connector

iPod docking cable

receptacle

receptacle

6

T

Verify that all connections have been properly made.

7 Reconnect the car's battery. est the unit before seating the cables and reinstalling the panels/trim.
