INSTALL THE 3 1/2” PULLEYS (P) INTO THE FRAME USING THE M10 x 43MM BOLTS (Z),
THE M10 FLAT WASHERS (HH), AND THE M10 LOCKNUTS(II).

LOWER PULLEY ASSEMBLY

P

Z

HH

I I

P

HH
