M e m o r y l a y o u t s
6 8
L x N E T E S U s e r ’ s G u i d e
upstream
LxNETES is based on various open source projects. The original source code
from these projects is stored in this folder. The following source code is
included:
Linux
Buildroot
U-Boot
This folder contains the source code of U-Boot including all patches which are
necessary for the specific target.
Memory layouts
Flash memory layout
The partitioning of the nonvolatile memory is described in this following table.
ConnectCore 9P 9360 / ConnectCore 9P 9750
SDRAM memory layout
The following tables describe some typical addresses in memory used by U-Boot and
Linux.
Flash Start Address
Size
Partition Name
mtdblock/
0x00000000
0x00040000
U-Boot
0
0x00040000
0x002C0000
Kernel
1
0x00300000
(Size of flash – 3MB)
rootfs
2
