SET ……….
ADVANCED
To enable the "Menu Advanced" enter the code (1234) using the UP, DOWN and ENTER keys.
SET - ADVANCED – SETUP ……….
RADIO
It assigns the desired command to the GLOW UP 'Radio' module choosing from one of the following:
•
Unlink Transmitter: Disconnected from the transmitter
• Link Receivers: Connected to all free receivers
• Unlink Receiver: Disconnected from all receivers
• Tx mode: It allows the user to select one of the two available transmission channels between G3
(recommended for those who do not use RDM-wireless commands) and G4 (only recommended if RDM-
wireless commands are used).
RDM discovery – to be used only when the wireless card is replaced; press ENTER to start the automatic
search option.
SET - ADVANCED – SETUP ……….
MODE
It allows the GlowUp operating mode to be assigned:
SLAVE PRIORITY: GlowUp operates as Slave, press ENTER to select the DMX signal reception priority in the
event of conflict between cable or wireless signal.
•
Cable (default)
• Wireless
MASTER OUTPUT: GlowUp operates as Master, press ENTER and use the UP and DOWN keys to select
how the DMX signal is transmitted to other devices:
•
Cable+Wireless
• Cable
• Wireless
REPEATER: GlowUp runs as a repeater.
In this case, select how GlowUP runs as a repeater meaning:
Direction: select whether the repeater should send the DMX signal from:
•
Wireless to Cable
• Cable to Wireless
Function: select whether the repeater should run from:
•
Repeat & Play (GlowUp repeats and plays)
• Repeat Only (GlowUp only runs as repeater)
To enable the REPEATER function, turn on (Enable) or off (Disable)
