EMX-NM70 User ’s Manual
8 EMX-NM70 User’s Manual
1.5 Specifications
System
CPU
 Intel® Celeron® Processor 1037U (2M Cache,1.80 GHz) upgradable with
Celeron level Processor
BIOS  AMI uEFI BIOS, 64Mbit SPI Flash ROM
System Chipset
 Intel® NM70 Express Chipset
I/O Chip  nuvoTon NCT6106D
System Memory
 1 x 204-pin DDR3 1333 SODIMMs, up to 8GB
Watchdog Timer
 H/W Reset, 1sec. – 65535sec./min.
 1sec. or 1min. step
H/W Status
Monitor
 CPU & system temperature monitoring
 Voltages monitoring
Buzzer
 Buzzer onboard
Expansion  1 x Mini PCI-e (Mini PCI-e and mSATA SSD is Switchable Through Jumper)
I/O
Rear Side External
I/O Connector
 1 x RJ-45
 2 x dual deck USB 2.0 connectors
 1 x VGA
 1 x HDMI
 1 x Mic-In and 1 x Line-out
 1 x DC Jack
Internal I/O
Connector
 Storage:
- 1 x SATA III connector
- 1 x SATA II connector
- 2 x SATA power connectors
 COM:
- COM1~2: support RS-232 connector, Pin 9 without / +5V&+12V supported
 GPIO: 8 bits
 1 x Mini PCI-e slot
 2 x 5 pin, pitch 2.54mm connector for USB 2.0
 2 x 1 x 3 pin, pitch 1.00mm CPU fan connector with smart fan function
supported
 1 x horizontal type battery connector
 1 x 2 x 5 pin, pitch 2.54mm connector for front panel
 1 x 2 x 2 pin ATX power connector for DC 19V input
 1 x 2 x 20 pin , pitch 1.00mm connector for LVDS
 1 x 5 pin , pitch 2.54mm connector for Inverter
