EMX-NM70 User ’s Manual
34 EMX-NM70 User’s Manual
S1 only(CPU Stop Clock)
S3 only(Suspend to RAM)
[Default]
Auto
when the SUSPEND button is pressed.
Wake By PME
Disabled
Enabled[Default]
Wakeup By PME.
USB Keyboard/Mouse
S3/S4 Wake
Disabled
Enabled[Default]
Enabled/Disabled Wakeup From S3/S4 By
USB KB/MS.
Power-Loss State
Always off[Default]
Always on
Keep last state
Control the status when Power loss occurs.
Poweron By RTC
Disabled[Default]
Enabled
Enable or disable System wake on alarm
event. When enabled, System will wake on the
hr::min::sec specified.
3.6.2.6 Super IO Configuration
You can use this item to set up or change the Super IO configuration for FDD controllers,
parallel ports and serial ports.
Item Description
Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA).
Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB).
