1.4.4

Removing a DDR2 DIMM

1. Press the two ejector tabs on the slot outward simultaneously, and then pull out the

DIMM module.

Support the DIMM lightly with your fingers when pressing the ejector
tabs. The DIMM might get damaged when it flips out with extra force.
