1.3.1 Layout Content List
Slots
Label Function Note Page
SO_DIMM 200-pin DDR2 SODIMM slot (Rear side) 15
MINIPCIE1 Mini PCI-e Slot 18
CF Compact Flash Card (Rear side) N/A
Jumpers
Label Function Note Page
CLRTC Clear CMOS 3 x 1 header, pitch 2.54mm 19
JCOMPWR1 COM1 RI/+5V/+12V Select 3 x 2 header, pitch 2.00mm 20
JCOMPWR2 COM1 RI/+5V/+12V Select 3 x 2 header, pitch 2.00mm 20
Rear Panel Connector
Label Function Note Page
KBMS1 PS/2 keyboard and mouse 6-pin Mini-Din 21
VGA1 VGA Connector D-sub 15-pin, female 21
USB1 USB 1&2 Connector 21
LAN1 RJ-45 Ethernet Connector 21
Audio2 Audio Line-out Port 21
DCIN1 12V DC-In Power Jack
Pin ψ2.5mm
21
Internal Connector
Label Function Note Page
FAN1 CPU Fan Connector 3 x 1 wafer, pitch 2.54mm 22
JLVDS LVDS Connector Hirose DF13S-40DP-1.25V 22
JBKL LCD Inverter Connector 5 x 1 header, pitch 2.00mm 23
FPANEL1 System Panel Connector (USB 5&6) 8 x 2 header, pitch 2.00mm 24
COM1 & 2 Serial Port Connector * 2 5 x 2 header, pitch 2.00mm 25
JDIO Digital I/O Connector 5 x 2 header, pitch 2.00mm 25
SATA1 & 2 SATA Data Connector * 2 7P Male connector 26
SATAPWR1 SATA Power Connector 2 x 2 female box header 26
JAUDIO1 Mic-In & Line-In Connector 5 x 2 header, pitch 2.00mm 27
USB2 USB 3&4 Connector 5 x 2 header, pitch 2.00mm 27
