EAX-Q87R User’s Manual
14 EAX-Q87R User’s Manual
- PCI Express® x 4Gen 3 8GT/s
- PCI 2.3 interface
- Six SATA ports (6 ports of Gen 3.0) support RAID 0,1, 5, 10
- Gigabit Ethernet Media Access Controller (GbE MAC)
IPv4 and IPv6 Checksum Offload
- High Definition Audio
- USB: Gen 2.0, up to 9 Ports / Gen 3.0, up to 4 Ports
- SMBus 2.0
- LPC Bus
Supports SPI devices
- Hardware Monitor
Fan control (Voltage, Temp)
Watchdog timer
• Power Management
- Dual Dynamic Power Management
Separate power planes for cores and memory controller
- Advanced Configuration and Power Interface (ACPI) 5.0
-
AMD PowerNow! and AMD Cool’n’Quiet technologies support
Before you Proceed
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
 Unplug the power cord from the wall socket before touching any
component.
 Use a grounded wrist strap or touch a safely grounded object or a
metal object, such as the power supply case, before handling
components to avoid damaging them due to static electricity
 Hold components by the edges to avoid touching the ICs on
them.
 Whenever you uninstall any component, place it on a grounded
anti-static pad or in the bag that came with the component.
 Before you install or remove any component, ensure that the ATX
power supply is switched off or the power cord is detached from
the power supply. Failure to do so may cause severe damage to
the motherboard, peripherals, and/or components.
