english 5 Yan Xtra / Ray Xtra
1. TECHNICAL DATA
As a stove of construction type 1, it is possible to
connect it to the chimney together with an existing
other stove or another hearth for solid fuels, as long
as the chimney calculation complies with DIN 4705,
Part 3.
TECHNICAL DATA Yan / Ray
Height
1480 mm 1368 mm
Width 490 mm 634 mm
Depth 400 mm 472 mm
Weight 263 kg 327 kg
Weight HMS 115 kg 115 kg
Flue pipe outlet diameter 150 mm 150 mm
Nominal thermal output 7 kW 7 kW
Max. thermal capacity 9 kW 9 kW
Smallest heating capacity 3,5 kW
Room heating capacity (depending on
building insulation)
82 – 210
m³
Exhaust values for multiple use of the chimney in
accordance with DIN 4705, Part 3 and for the
calculation of the chimney measurements in
accordance with DIN 4705, Part 2
Fluegas mass flow
closed 5,4 g/s
Fluegas temperature closed 340 °C
Minimum feed pressure
Nominal thermal output
closed
12 Pa
at 0.8 times
n. ther. outp.
10 Pa
2. IMPORTANT INFORMATION
The installation and operation information given here
is of general nature
. National and European
standards, local and building regulations as well as
fire prevention laws must be observed during the
operation of the stove.
General safety instructions for
the operation of your stove
•
Read the entire manual before starting up your
stove thoroughly and observe the caution notices.
•
Your heating unit must not be moved without
approved means of transport with sufficient load-
bearing capacity.
•
Your heating unit is not suitable to be used as a
stand or as a ladder.
•
Please keep in mind that
your stove’s surface heats up
considerably during operation. We
therefore recommend wearing a
safety mitten when operating your
stove.
•
Make your children aware of this particular
danger and keep them at a distance from the heating
unit whenever it is in operation.
•
Only burn approved fuels and materials as listed
in the chapter “Clean Burning”.
•
The burning or placing of flammable or explosive
materials, such as empty spray cans, etc. into the
firebox as well as the storage of such materials in the
immediate vicinity of your heating unit is strictly
forbidden due to the danger of explosion.
•
Do not wear loose or flammable clothing when
adding fuel to the fire.
•
Placing non-heat-resistant objects on the
heating unit or in the vicinity of the heating unit is
forbidden.
•
Do not lay laundry onto the stove for drying.
Laundry hung up to dry must be kept at a safe
distance from the stove because of the danger of fire.
•
The wood stove is not suitable for long term
heating.
• During the operation of your heating unit it is
forbidden to use flammable or explosive materials in
the same or an adjacent room to the one in which
your heating unit is located.
•
The appliance must be operated with the stove
door closed.
•
The stove door and all fittings for adjusting the
stove must be closed, if the appliance is out of use.
Setting up your stove
Required safety distances
(Minimum
distances – see name plate - in Fig. 2)
a > 800 mm - towards the front in the radiated area
b > 100 mm – to the side
c > 110 mm – to the back
Make sure that the room in which the stove is set up
has at least one door or window into the outside or is
directly adjacent to such a room. Other fireplaces and
extractor hoods must not be operated in the same
room as the stove
.
