D/A Performance
Dynamic Range: 112 dB unweighted, 115 dB A-weighted
Sample Rate: 48kHz
D/A Wordlength: 24 bits
System Performance
Internal Wordlength: 48 bits
THD + Noise: 0.003% typical at +4dBu, 1kHz, 0dB input gain
Frequency Response: 20Hz- 20kHz, +/-0.5dB
Interchannel Crosstalk: <-85dB at 1kHz, 0dB input gain
Pre EQ
Type: One 31-band Graphic EQ per input channel, or
9 band Parametric EQ per input channel
RTA can be substituted for EQ in channels 3 and 4
Range: +/-12 dB range
Notch Filters
Number: 1-5 per input channel not to exceed 10 for all input channels
Pre Delay
Length: 680ms/channel
Crossover
Type: 1x2, 1x3, 1x4, 1x5, 1x6
2x3, 2x4, 2x5, 2x6, 2x7, 2x8, 3x4, 3x5, 3x6, 3x7, 3x8, 4x6, 4x8
Filter Type: Butterworth, Bessel, or Linkwitz-Riley
Slope: 6, 12, 18 or 24 dB/octave for Butterworth or Bessel filters
12, 24, 36 or 48 dB/octave for Linkwitz-Riley filters
Post EQ
Type: Parametric
Number: 4 EQ bands per output channel
Range: +/-15 dB range
Dynamics
Type: Compressor/Limiter with PeakStopPlus™
Attack/Release: Program Dependent
Linking: All 8 bands are linkable
Post Delay (Driver Alignment)
Length:
170 ms per output channel
Pink Noise Generator
Position: Pink noise inserted on selected input(s)
Phase Compensation
Number: One per output channel
Amount: 0-180 degrees phase shift
Output Polarity: Reversible
Miscellaneous
Output Transformers: Optional
Network: Proprietary RS-485 Backbone
GUI: RS-232 interface for computer display and
configuration
Remote: Optional dbx 480R
RTA Microphone: Optional
ROM Upgrade: Flash upgradeable through RS-232
Power Requirements
Watts: 100-240V - 50/60 Hz
35 Watts
Dimensions
Dimensions: Height- 1.75” X Width- 19” X Depth 7.90”
Weight 8 lbs.
Shipping Weight: 9.5 lbs.
Appendix A
DriveRack ™
DriveRack™ User Manual 97
