dbx Pro 215 User Manual

Dual 15-band graphic equalizer

8760 S. Sandy Pkwy.

Sandy, Utah 84070

Phone (801) 568-7660

Fax (801) 568-7662

Int’l Fax (801) 568-7583

http://www.dbxpro.com

A Harman International Company

18-0115-A 7/02

215

Dual 15-Band Graphic Equalizer

The dbx 2-Series Graphic Equalizers have been designed to meet the needs of the most

demanding sound reinforcement environments, while offering the simplicity of straight for-

ward controls. The 215 not only provides standard features like dual channels, 15 2/3 octave

bands, ISO frequency centers, +/-12 dB input gain range, and switchable 50Hz/12 dB per

octave low-cut filters, but also includes other thoughtful features. These features include: 20

mm faders; selectable +/-6dB or +/-12dB boost/cut range for precise gain adjustments; XLR,

and 1/4'' TRS connectors for installation ease; balanced inputs and outputs for quiet opera-

tion; and chassis/signal ground lift capabilities for quick hum isolation. The visionary design

of the dbx 2-Series has been pursued to make your job easier.

The 2-Series represents a major step forward in the performance of entry-level graphic

equalizers. From its amazing 10Hz to 50kHz frequency response, to its 108dB dynamic

range, internal toroidal transformer, the 2-Series offers out of this world specifications with

a down to earth price point. Sure to find a home in the studio, on tour and with installed

sound venues, the 2-Series is destined to take its rightful place in the lineage of great dbx®

signal processors that are the professional’s choice in signal processing. With such afford-

able quality, there’s no longer any excuse for compromising your sound.

• Two 15-band, 2/3-octave Constant

Q frequency bands

• Switchable boost/cut ranges of ±6

or ±12 dB

• 12 dB per octave, 3dB down @

50Hz low-cut filter

• Front panel bypass switch

• ±12 dB input gain range

• 4-segment LED ladders for moni-

toring output levels

• XLR and TRS Inputs and Outputs

• Internal Toroidal Transformer

• Frequency Response of <10 Hz to

>50kHz

• Dynamic range of greater than

108dB
