LCD Display

The front panel is equipped with a 2 row by 16-character display.

The basic function of the display is:

-

Display the printer status

-

Display the printer settings

-

Display's prompts requesting input data from a keyboard or barcode reader.

Standard Printer

After power ON the following message is displayed on the LCD

(203, PAL/PPLZ)

The first parameter is either 203 or 300. It indicates the print resolution.

The second parameter indicates the emulation (printer language), PAL/PPLZ, PPLA or
PPLB.

With Keyboard Option installed

If a keyboard is plugged in and PAL app loaded, the following message is displayed
on the LCD

(203, PAL/PPLZ)

FOR KEYBD

With Barcode Reader Option

If a barcode reader is connected and PAL app loaded, the following message is displayed
on the LCD.

(203, PAL/PPLZ)

WITH B.C. READER

Abnormal Conditions

If any abnormal condition occurs the related message will be displayed. For example:

RIBBON OUT
