0613-01
4
ADVANCED CONTROL TECHNOLOGIES, INC.
Indianapolis, Indiana 46278
RD124 Installation Instructions
P/D 102102
Supply Voltage: 120 VAC, +/-10%, 50 or 60 Hz
Maximum switching power: 300W
Signal Input: 120 KHz +/- 4 KHz, sensitive to 50 millivolts
DATABYTE
G1 G0 0 1 X X X X Turn OFF RD124’s on specified LETTERCODE that are in
specified group.
DATABYTE
G1 G0 1 0 S
3
S
2
S
1
S
0
Turn ON RD124’s on specified LETTERCODE that are in
specified group. Group address is relative to group reference
S
3
S
2
S
1
S
0
DATABYTE
G1 G0 1 1 S
3
S
2
S
1
S
0
Turn OFF RD124’s on specified LETTERCODE that are in
specified group. Group address is relative to group reference
S
3
S
2
S
1
S
0
CHECKOUT
1. Test Remote Operation: Using the transmitter, transmit the address and any programmed
commands to ensure the module controls the load in response to remote control.
2. Test for Signal Strength and Noise once again using appropriate PCC test equipment.
