EXTENDED CODE COMMANDS
An extended code message is as follows:
LETTERCODE EXTENDEDCODE1 NUMBERCODE DATABYTE TYPE COMMAND
Here are some examples:
A [EXTC1] 01 09 31 = Turn Lamp on to level 9
A [EXTC1] 01 01 35 = Remove units set to Lettercode A and Numbercode 1 from Group 1
The RD124 supports some TYPE 3 Extended Code 1 commands. They are listed below.
Command 0
DATABYTE
G1 G0 0 X X X X X Include in Group G1G0 at the current level on specified
LETTERCODE and NUMBERCODE
DATABYTE
G1 G0 1 X S
3
S
2
S
1
S
0
Include in Group G1G0 at the current level on specified
LETTERCODE and NUMBERCODE. Group address is relative to
group reference S
3
S
2
S
1
S
0
Command 1
DATABYTE
X X B16 B8 B4 B2 B2 B1 Preset RD124 to the level specified in ‘B’ field on specified
LETTERCODE and NUMBERCODE
(Sending Maximum level will cause RD124 to immediately go to that
level without ramping).
Command 2
DATABYTE
G1 G0 B16 B8 B4 B2 B1 Include in Group G1G0 on specified LETTERCODE and
NUMBERCODE at the level specified in the ‘B’ field
Command 3
DATABYTE
X X X X X X X X All Units On on specified LETTERCODE
Command 4
DATABYTE
X X X X X X X X All Units Off on specified LETTERCODE
Command 5
DATABYTE
0 0 0 0 G3 G2 G1 G0 Remove from Group on specified LETTERCODE and
NUMBERCODE
DATABYTE
1 1 1 1 G3 G2 G1 G0 Remove from Group on specified LETTERCODE
(G3 G2 G1 G0) is bit mapped.
Command 6
DATABYTE
G1 G0 0 0 X X X X Turn ON RD124’s on specified LETTERCODE that are in
specified group.
