0613-01
2
ADVANCED CONTROL TECHNOLOGIES, INC.
Indianapolis, Indiana 46278
RD124 Installation Instructions
P/D 102102
OPERATION
With any controller that supports X10 commands, the RD124 can be remotely turned on and off, or
it can be dimmed or brightened.
To manually turn the module on and off, tap the push-button on front of the unit quickly. To dim or
brighten, press and hold the button.
If power is lost, upon restoration the output will come on at the last level before power was lost.
ADVANCED OPERATION
RESOLUTION
The number of levels available on the RD124 is dependent upon the type of commands used to
control it. The RD124 supports standard code dim/bright commands, standard code preset dim
commands, and extended code commands.
Using standard code dim/bright commands; there are 16 available levels.
Using standard code preset dim commands; there are 32 available levels.
Using extended code commands; there are 64 available levels.
STANDARD CODE DIM/BRIGHT COMMANDS
While the RD124 receives standard dim/bright commands it will dim or brighten to the selected
level as the Dim or Bright button is held, or if commanded, until it is completely off or fully on.
STANDARD CODE PRESET DIM COMMANDS
The advantage of Preset Dim commands are that the RD124 can be commanded to go to a
specific dim level without having to know its current level.
An explanation of Preset Dim commands is needed if the user is going to control the RD124
through Standard Code Preset Dim commands.
Explanation
Just like any other command, before the RD124 will accept a Preset Dim command it has to be
addressed. After the RD124 is addressed, a Preset Dim command can be sent.
A Preset Dim command is composed of a House Code combined with either the Preset Dim 0
command or Preset Dim 1 command. This combination makes up the 32 different levels avail-
able. The 32 House Code/ Preset Dim 0/1 combinations are listed below by level.
To set a RD124 to level 16, J PresetDim0 would be the command.
Level Command Level Command
1 (Full Off) M PresetDim0 17 M PresetDim1
2 N PresetDim0 18 N PresetDim1
3 O PresetDim0 19 O PresetDim1
4 P PresetDim0 20 P PresetDim1
5 C PresetDim0 21 C PresetDim1
6 D PresetDim0 22 D PresetDim1
7 A PresetDim0 23 A PresetDim1
8 B PresetDim0 24 B PresetDim1
9 E PresetDim0 25 E PresetDim1
10 F PresetDim0 26 F PresetDim1
11 G PresetDim0 27 G PresetDim1
12 HPresetDim0 28 HPresetDim1
13 K PresetDim0 29 K PresetDim1
14 L PresetDim0 30 L PresetDim1
15 I PresetDim0 31 I PresetDim1
16 J PresetDim0 32 (Full On) J PresetDim1
