ADLINK EXP-ETH8 User Manual
Page 21

TME-EXP-ETH8-1V3
Rev 1.3
Page 17 of 17
127
Pex16_0R(11)p
128
Pex16_0R(3)p
129
Pex16_0R(11)n
130
Pex16_0R(3)n
131
GND
132
GND
133
Pex16_0R(12)p
134
Pex16_0R(4)p
135
Pex16_0R(12)n
136
Pex16_0R(4)n
137
GND
138
GND
139
Pex16_0R(13)p
140
Pex16_0R(5)p
141
Pex16_0R(13)n
142
Pex16_0R(5)n
143
GND
144
GND
145
Pex16_0R(14)p
146
Pex16_0R(6)p
147
Pex16_0R(14)n
148
Pex16_0R(6)n
149
GND
150
GND
151
Pex16_0R(15)p
152
Pex16_0R(7)p
153
Pex16_0R(15)n
154
Pex16_0R(7)n
155
GND
156
GND
