TME-EXP-ETH8-1V3 Rev 1.3 Page 16 of 17
Pin Signal Pin Signal
53 WAKE#
+5V
54 PEG EN#
55 GND 56 GND
57 Pex16_0T(8)p 58 Pex16_0T(0)p
59 Pex16_0T(8)n 60 Pex16_0T(0)n
61 GND 62 GND
63 Pex16_0T(9)p 64 Pex16_0T(1)p
65 Pex16_0T(9)n 66 Pex16_0T(1)n
67 GND 68 GND
69 Pex16_0T(10)p 70 Pex16_0T(2)p
71 Pex16_0T(10)n 72 Pex16_0T(2)n
73 GND 74 GND
75 Pex16_0T(11)p 76 Pex16_0T(3)p
77 Pex16_0T(11)n 78 Pex16_0T(3)n
79 GND 80 GND
81 Pex16_0T(12)p 82 Pex16_0T(4)p
83 Pex16_0T(12)n 84 Pex16_0T(4)n
85 GND 86 GND
87 Pex16_0T(13)p 88 Pex16_0T(5)p
89 Pex16_0T(13)n 90 Pex16_0T(5)n
91 GND 92 GND
93 Pex16_0T(14)p 94 Pex16_0T(6)p
95 Pex16_0T(14)n 96 Pex16_0T(6)n
97 GND 98 GND
99 Pex16_0T(15)p 100 Pex16_0T(7)p
101 Pex16_0T(15)n 102 Pex16_0T(7)n
103 GND 104 GND
PIN Signal PIN Signal
105 SDVO DAT
+12
V
106 SDVO CLK
107 GND 108 GND
109 Pex16_0R(8)p 110 Pex16_0R(0)p
111 Pex16_0R(8)n 112 Pex16_0R(0)n
113 GND 114 GND
115 Pex16_0R(9)p 116 Pex16_0R(1)p
117 Pex16_0R(9)n 118 Pex16_0R(1)n
119 GND 120 GND
121 Pex16_0R(10)p 122 Pex16_0R(2)p
123 Pex16_0R(10)n 124 Pex16_0R(2)n
125 GND 126 GND
