8 Connectors & Jumpers
Table 2-1: AmITX-IB-I Onboard Connector Labels Legend
ATX12V1
ATX 12V Power connector
CLCMOS
Clear CMOS jumper
COM2~6
COM pin header
CPU_FAN1
CPU Fan connector
EATXPWR1
ATX Power connector
F_PANEL System Panel header
FPAUD1
Audio Mic.-In, Line-Out header
JDIO
GPIO pin header
JPSON1
AT/ATX power mode select jumper
MINI-PCIE
Mini-PCIe slot
PCIEX4
PCIe x4 slot
SATA1 ~ 2
SATA connectors
SODIMM 1
204-pin DDR3 SO-DIMM Slot A1
SODIMM 2
204-pin DDR3 SO-DIMM Slot B1
SPI1
SPI pin header
SYS_FAN1
System Fan connector
USB78
USB pin header
USB9
USB Vertical-type connector
