ADLINK CoreExpress-ECO2 User Manual
Page 20
TME-CEM-ECO2-Rev0V4.doc
Rev 0.4
Page 16
B1
GND (connected to metal shroud)
POWER
0V
no
B2
PCIE_RXAn
PCIexpress
AC coupled
yes
B3
PCIE_RXAp
PCIexpress
AC coupled
yes
B4
PCIE_CLKBn
PCIexpress
3.3V
yes
B5
PCIE_CLKBp
PCIexpress
3.3V
yes
B6
GND
POWER
0V
no
B7
PCIE_RXBn
PCIexpress
AC coupled
yes
B8
PCIE_RXBp
PCIexpress
AC coupled
yes
B9
PCIE_RXCn
PCIexpress
AC coupled
yes
B10
PCIE_RXCp
PCIexpress
AC coupled
yes
B11
GND (connected to metal shroud)
POWER
0V
no
B12
PCIE_CLKDn (w/o EG20T available)
PCIexpress
3.3V
yes
B13
PCIE_CLKDp (w/o EG20T available)
PCIexpress
3.3V
yes
B14
PCIE_RXDn (w/o EG20T available)
PCIexpress
AC coupled
yes
B15
PCIE_RXDp (w/o EG20T available)
PCIexpress
AC coupled
yes
B16
GND
POWER
0V
no
B17
CLKREQB#
PCIexpress
3.3V
no
B18
CLKREQD# (w/o EG20T available)
PCIexpress
3.3V
no
B19
SDVO_INT#
SDVO
AC coupled
yes
B20
SDVO_INT
SDVO
AC coupled
yes
B21
GND (connected to metal shroud)
POWER
0V
no
B22
SDVO_BLUE
SDVO
AC coupled
yes
B23
SDVO_BLUE#
SDVO
AC coupled
yes
B24
SDVO_STALL
SDVO
AC coupled
yes
B25
SDVO_STALL#
SDVO
AC coupled
yes
B26
GND
POWER
0V
no
B27
SDVO_CTRL_CLK
SDVO
AC coupled
yes
B28
SDVO_CTRL_DAT
SDVO
AC coupled
yes
B29
LA_DATA1p
LVDS
Low voltage
yes
B30
LA_DATA1n
LVDS
Low voltage
yes
B31
GND (connected to metal shroud)
POWER
0V
no
B32
LA_CLKp
LVDS
Low voltage
yes
B33
LA_CLKn
LVDS
Low voltage
yes
B34
L_BKLTCTL
LVDS
3.3V
no
B35
L_BKLTEN
LVDS
3.3V
no
B36
L_DETECT
LVDS
3.3V
no
B37
L_VDDEN
LVDS
3.3V
no
B38
USB_C_DEVICE
USB2.0
3.3V
no
B39
USB_Bp
USB2.0
Low voltage
yes
B40
USB_Bn
USB2.0
Low voltage
yes
B41
GND (connected to metal shroud)
POWER
0V
no
B42
USB_Dp
USB2.0
Low voltage
yes
B43
USB_Dn
USB2.0
Low voltage
yes
B44
USB_Fp
USB2.0
Low voltage
yes
B45
USB_Fn
USB2.0
Low voltage
yes
B46
GND
POWER
0V
no
