4 Overview
Mechanical Specifications
Figure 1-4: Mechanical Dimensions (Top Side)
Power Specifications
Table 1-4 provides the power requirements for this module.
Operating configurations:
 In-rush operating configuration - To be determined
 Idle operating configuration - To be determined
 *BIT = Burn-In-Test operating configuration - To be determined
All dimensions are given in inches and millimeters.
Table 1-4: Power Supply Requirements
Parameter
600Mhz
Characteristics
Input Type Regulated DC voltage
In-rush
Voltage & Current Not yet measured
Typical Idle
Voltage & Current Not yet measured
BIT*
Voltage & Current Not yet measured
J1
1.54 (39.00mm) 3.07 (78.00mm) 3.16 (80.30mm) 3.23 (82.0mm) 2.14 (54.39mm) 1.08 (27.39mm) 0.16 (4.00mm) 0.00
0.00
1.97 (50.00mm)
1.81 (46.00mm)
0.47 (12.00mm)
0.30 (7.70mm)
0.24 (6.20mm)
0.78 (19.69mm)
1.44 (36.69mm)
LEC_3517_Top_Dmn_a
