ADLINK nanoX-TCR User Manual
Page 31
Chapter 3
Hardware
nanoX-TCR
Reference Manual
27
A62
PCIE2_TX- (Occupied by PCH - PCIE0) B62
PCIE2_RX- (Occupied by PCH - PCIE0)
A63
GPI1
B63
GPO3
A64
PCIE1_TX+
B64
PCIE1_RX+
A65
PCIE1_TX-
B65
PCIE1_RX-
A66
GND
B66
WAKE0# (PU 1k 3.3V S5 Standby)
A67
GPI2
B67
WAKE1# (PU 1k 3.3V S5 Standby)
A68
PCIE0_TX+
B68
PCIE0_RX+
A69
PCIE0_TX-
B69
PCIE0_RX-
A70
GND
B70
GND
A71
LVDS_A0+
B71
DDIO_PAIR0+ (SDVO_RED+)
A72
LVDS_A0-
B72
DDIO_PAIR0- (SDVO_RED-)
A73
LVDS_A1+
B73
DDIO_PAIR1+ (SDVO_GREEN+)
A74
LVDS_A1-
B74
DDIO_PAIR1- (SDVO_GREEN-)
A75
LVDS_A2+
B75
DDIO_PAIR2+ (SDVO_BLUE+)
A76
LVDS_A2-
B76
DDIO_PAIR2- (SDVO_BLUE-)
A77
LVDS_VDD_EN (PD 10k)
B77
DDIO_PAIR4+ (SDVO_INT+)
A78
LVDS_A3+
B78
DDIO_PAIR4- (SDVO_INT-)
A79
LVDS_A3-
B79
LVDS_BKLT_EN (Backlight Enable)
A80
GND
B80
GND
A81
LVDS_A_CK+
B81
DDIO_PAIR3+ (SDVO_CLK+)
A82
LVDS_A_CK-
B82
DDIO_PAIR3- (SDVO_CLK-)
A83
LVDS_I2C_CK (PU 2.2k 3.3V
S5 Standby)
B83
LVDS_BKLT_CTRL (Backlight Brightness)
A84
LVDS_I2C_DAT (PU 2.2k 3.3V
S5 Standby)
B84
VCC_5V_SBY
A85
GPI3 (PU 10k 3.3V S5 Standby) B85
VCC_5V_SBY
A86
RSVD
B86
VCC_5V_SBY
A87
RSVD
B87
VCC_5V_SBY
A88
PCIE_CK_REF+
B88
BIOS_DS1# (PU 10k 3.3V Standby)
A89
PCIE_CK_REF-
B89
DD0_HPD (Hot Plug Detect - PU
10k 3.3V Standby)
A90
GND
B90
GND
A91
SPI_POWER (3.3 V S5 Standby) B91
DDIO_PAIR5+
(SDVO_TVCLKINP)
A92
SPI_MISO
B92
DDIO_PAIR5-
(SDVO_TVCLKINN)
A93
GPO0
B93
DDIO_PAIR6+ (SDVO_STALLP)
A94
SPI_CLK
B94
DDIO_PAIR6- (SDVO_STALLN)
A95
SPI_MOSI
B95
RSVD
A96
NC (Not Connected)
B96
RSVD
A97
NC (Not Connected)
B97
SPI_CS# (SPI Chip Select for Carrier)
Table 3-5. COM Express A-B Connector Signal Descriptions (Continued)
