Chapter 2 Product Overview
nanoX-TCR Reference Manual 13
Specifications
Physical Specifications
Table 2-4 lists the physical dimensions of the module.
Table 2-4. Weight and Footprint Dimensions
Item Dimension
NOTE Overall height is measured from the
upper board surface to the highest
permanent component on the upper
board surface. This measurement does
not include the cooling solution. The
heights of the board with the cooling
solutions are 15.00mm (0.43 inches) for
the heatsink and 11.00mm (0.59 inches)
for the heatspreader.
See
Figure 2-7 on page 16 for an
illustration of the cooling solution stack
heights.
Weight 0.04 kg (0.10 lb)
Height (overall) 3.10 mm (0.12 inches)
Board thickness 2.36 mm (0.093 inches)
Width 55.00 mm (2.17 inches)
Length 84.00 mm (3.31 inches)
