Page 10 nanoX-BT
2.5. Video
¾ GPU Feature Support: 7th generation graphics Intel core architecture with four execution units supporting two independent displays
• 3D graphics hardware acceleration
• Support for DirectX11, OCL 1.1, OGL ES Halt/2.0/1.1, OGL 3.2
• Video decode hardware acceleration including support for H.264, MPEG2, VC-1, WMV and VP8 formats
• Video encode hardware acceleration including support for H.264, MPEG2 and MVC formatsPlayback of Blu-ray disc S3D content using HDMI
(1.4a spec compliant with 3D)
Note: Availability of features may vary between operating systems
¾ Display Interface support
• LVDS
Single channel 18/24-bit LVDS from eDP (one lane)
Build option upon request to support eDP output
• DDI0
Supports DisplayPort / HDMI / DVI / eDP
2.6. Audio
¾ Integrated: Intel® HD Audio integrated in SOC
¾ Audio Codec: located on evaluation carrier miniBase-10R (ALC262 standard supported)
2.7. LAN
¾ Type: Intel® i210 (MAC/PHY) Ethernet controller
¾ Interface: 10/100/1000 GbE connection
2.8. Multi I/O and Storage
¾ Integrated in SOC
¾ USB:
• 1x USB. 1.1/2.0/3.0 (USB 0)
• 3x USB. 1.1/2.0 (USB 1,2,3)
• 1x USB. 1.1/2.0 Client (USB 7)
¾ SATA: 2x ports SATA 3Gb/s (SATA0, SATA1)
¾ eMMC: optional soldered on module bootable eMMC flash storage (8GB/16GB/32GB)
¾ Serial: 2x UART ports COM 0/1 (COM 1 supports console redirection)
¾ SD: optional SD signal support mulitplexed over GPIO pins
¾ GPIO: 4x GPO and 4x GPI with interrupt
2.9. Power Specifications
¾ Power Modes: AT and ATX mode (AT mode start controlled by SEMA)
¾ Standard Voltage Input: ATX = 12V±5%, 5Vsb ±5% or AT = 12V ±5%
¾ Wide Voltage Input: ATX = 5~14 V, 5Vsb ±5% or AT = 5 ~14V
¾ Power Management: ACPI 4.0 compliant, Smart Battery support
¾ Power States: supports C1-C6, S0, S1, S4, S3, S5, S5 ECO mode (Wake on USB S3/S4, WOL S3/S4/S5)
¾ ECO mode: supports deep S5 for 5Vsb power saving
