Page 70 Express-HLE
Feature Options Description
Turn off unused PCI/PCIe clocks Disabled
Enable Disabled: all clocks turned on.
Enabled: clocks for empty PCI/PCIe slots will be turned off to save
power. Platform must be powered off for changes to take effect.
ICC Locks After EOP Default
All Locked
All UnLocked Lock ICC register after EOP.
Clock Manipulation Info only
ICC Overclocking Lib Info only
CLKRUN# Logic Enabled
Disabled Enable the CLKRUN# logic to stop the PCI clock.
7.3.13 Thermal
Feature Options Description
Thermal Info only
Automatic Thermal Reporting
Enabled
Disabled Configure _CRT, _PSV and _AC0 automatically based on values
recommended in BWG’s Thermal Reporting for Thermal
Management settings. Set to Disabled for manual conmfiguration.
Critical Trip Point Disabled
85 C
95 C This value controls the temperature of the ACPI Critical Trip Point -
the point in which the OS will shut the system off.
NOTE: 100C is the Plan Of Record (POR) for all Intel mobile
processors.
Active Trip Point Disabled
40 C
50 C
60 C
70 C
BMC Default This value controls the temperature of the ACPI Active Trip Point -
the point in which the OS will turn the processor fan on Active Trip
Point Fan Speed.
Passive Trip Point Disabled
80 C
90 C This value controls the temperature of the ACPI Passive Trip Point -
the point in which the OS will begin throttling the processor.
Passive TC1 Value 1 This value sets the TC1 value for the ACPI Passive Cooling
Formula. Range 1 – 16.
Passive TC2 Value 5 This value value sets the TC2 value for the ACPI Passive Cooling
Formula. Range 1 - 16
Passive TSP Value 10 This item sets the TSP value for the ACPI Passive Cooling Formula.
It represents in tenths of a second how often the OS will read the
temperature when passive cooling is enabled. Range 2 – 32.
Watchdog ACPI Even Shutdown Disabled
Enable Enable/Disable Watchdog ACPI Even Shutdown.
7.3.14 Miscellaneous
Feature Options Description
High Precision Timer Enabled
Disabled Enable/Disable the High Precision Event Timer.
Security
BIOS Security Configuration Submenu
