Page 60 Express-HLE
Feature Options Description
Software Feature Mask Configuration Info only
RAID0 Enabled
Disabled Enable/Disable RAID0 feature.
RAID1 Enabled
Disabled Enable/Disable RAID1 feature.
RAID10 Enabled
Disabled Enable/Disable RAID10 feature.
RAID5 Enabled
Disabled Enable/Disable RAID5 feature.
Intel Rapid Recovery Technology Enabled
Disabled Enable/Disable Intel Rapid Recovery Technology.
OROM UI and BANNER Enabled
Disabled If enabled, then the OROM UI is shown. Otherwise, no OROM
banner or information will be displayed if all disks and RAID volumes
are Normal.
HDD Unlock Enabled
Disabled If enabled, indicates that the HDD password unlock in the OS is
enabled.
LED Locate Enabled
Disabled If enabled, indicates that the LED/SGPIO hardware is attached and
ping to locate feature is enabled on the OS.
IRRT Only on ESATA Enabled
Disabled If enabled, then only IRRT volumes can span internal and eSATA
drives. If disabled, then any RAID volume can span internal and
eSATA drives.
Smart Response Technology Enabled
Disabled Enable/Disable Smart Response Technology.
OROM UI Delay Enabled
Disabled If enabled, indicates the delay of the OROM UI Splash Screen in a
normal status.
7.3.4.1 SATA > Intel® Rapid Start Technology
Feature Options Description
Intel (R) Rapid Start Disabled
Enabled Enable/Disable Intel (R) Rapid Start.
Entry on S3 RTC Wake Disabled
Enabled RapidStart invocation upon S3 RTC wake.
Entry After 10
Enable RTC wake timer at S3 entry. Value range from
0(Immediately) to 120 minutes.
Active Page Threshold Disabled
Enabled Support RST with small partition.
Hybrid Hard Disk Support
Disabled
Enabled Hybrid Hard Disk Support.
RapidStart Display Save/Restore Disabled
Enabled RapidStart Display Save/Restore.
7.3.4.2 SATA > SATA Port Configuration
Feature Options Description
SATA Port Configuration Info only
Port X Disabled
Enabled Enable/Disable SATA Port.
