ADLINK Express-HLE - Manual (Page 54)

Page 54 Express-HLE
7.2.4.6 System Management > Power Up
Feature Options Description
Power Up Info only
Power Up watchdog
Attention: F12 disables the Power Up
Watchdog. Enabled
Disabled The Power-Up Watchdog resets the system after a certain
amount of time after power-up.
ECO Mode Disabled
Enable Reduces the power consumption of the system.
Power-up Mode
Attention: The Power-Up Mode only has effect,
if the module is in ATX-Mode.
Turn on
Remain off
Last State Turn On: The machine starts automatically when the power
supply is turned on.
Remain Off :To start the machine the power button has to be
pressed.
Last State: when powered on during a power failure the system
will automatically power on when power is restored
7.2.4.7 System Management > LVDS Backlight
Feature Options Description
LVDS Backlight Info only
LVDS Backlight Bright 255 The value range starts by 0 and ends by 255.
7.2.4.8 System Management > Smart Fan
Feature Options Description
Smart Fan Info only
CPU Smart FanTemperature Source CPU Sensor
System Sensor Select CPU smart fan source.
CPU Fan Mode AUTO (Smart Fan)
Fan Off
Fan On Select CPU Fan Mode.
CPU Trigger Point 1 Read only
Trigger Temperature 15 Specifies the temperature threshold at which the BMC turns on
CPU fan with specific PWM level.
PWM Level 30 Select PWM level.
CPU Trigger Point 2 Read only
Trigger Temperature 60 Specifies the temperature threshold at which the BMC turns on
CPU fan with specific PWM level.
PWM Level 40 Select PWM level.
CPU Trigger Point 3 Read only
Trigger Temperature 70 Specifies the temperature threshold at which the BMC turns on
CPU fan with specific PWM level.
PWM Level 63 Select PWM level.
CPU Trigger Point 4 Read only
Trigger Temperature 80 Specifies the temperature threshold at which the BMC turns on
CPU fan with specific PWM level.
PWM Level 100 Select PWM level.
