32
•
Utility/Calibration
6
Utility / Calibration
The software CD provides a utility program, 6208util.exe, and is intended
for calibration and functional testing. The utility is a menu-driven design
and operates under the DOS environment. The text messages gives
operating guidance, with graphics to indicate correct hardware
configuration and location. The utility is described in the following sections.
6.1 Running the 6208util.exe
After finishing the DOS installation, you can execute the utility by typing
the following command. (Assuming your utility is located in
\ADLINK\DOS\6208\Util directory), the following command should be
entered at the DOS prompt.
C> cd \ADLINK\DOS\6208\Util
C> 6208UTIL
The following diagram will be displayed on your screen. The message at
the bottom of each window guides you through the selected item.
Figure 9: Main selection Menu
