AR-B1622 User’s Guide

7

2.2.2 VJP1 (LCD 3V or 5V)

2.2.3 COM1＆COM2

2.2.4 JFRT1

2.2.4 VGA1

PIN

DEFINE

1-2 3V

2-3 5V

PIN DEFINE PIN DEFINE

1 -DCD

2 -DSR

3 SIN

4 -RTS

5 SOUT

6

-CTS

7 -DTR

8 -RI

9 GND

10

GND

PIN DEFINE

1-2 RESET

3-4

PIN 3：5V（PWR LED）

PIN 4：GND

5-6

PIN 5：5V

PIN 6：HD LED

7-8

PIN 7：SPEAKER+

PIN 8：SPEAKER-

9-10 NC

PIN DEFINE PIN DEFINE

1 RED

2 GND

3 GREEN

4

GND

5 BLUE

6

GND

7 V-SYNC

8 SSCL

9 H-SYNC

10 SSDA

1

3

2

1

10

9

2

1

10

9

2

1

10

9
